Cisco C819G-4G-V-K9 C819 M2M 4G LTE Verizon 700 MHz Band 13 Wireless Integrated Services Router

The Cisco® 819 Integrated Services Router Family, designed in compact hardened and non-hardened form factors, is the smallest Cisco IOS® Software router with support for integrated fourth-generation (4G LTE) wireless WAN (mobile broadband backhaul) and WLAN capabilities. The Cisco 819 ISR gateway provides a rapidly deployable, highly available, reliable, and secure solution designed specifically for machine-to-machine (M2M) applications. Markets that benefit from these applications include industrial automation, transportation, financial, health care, utility, and retail. Fully integrated with Cisco IOS Software, the Cisco 819 family delivers, enterprise-class features, including highly secure data, voice, and video communications to stationary and mobile network nodes across wired and wireless links. Figure 1 shows a Cisco 819HG Integrated Services Router.

Product Name: C819 M2M 4G Lte Verizon 700 MHz Band 13
Product Type: Wireless Integrated Services Router
Broadband Transmission Technology: Cellular
ISM Band: No
UNII Band: No
Ethernet Technology: Gigabit Ethernet
Number of Network (RJ-45) Ports: 4
Cellular Data Connectivity Technology: LTE
Cellular Generation: 4G
Cellular Network Supported: LTE 700
Number of Broadband (RJ-45) Ports: 1
Height: 1.7"
Width: 8.1"
Depth: 7.7"
Product Series: 800
Form Factor: Wall Mountable, Desktop
Product Model: 819G
Expansion Slots: 2 x SIM Card
Antenna Type: Dipole Antenna
Antenna Connector: TNC Connector
USB: Yes
VGA: No
Network (RJ-11): No
Powerline: No
Management Port: Yes
Serial: Yes
VoIP Supported: Yes
PoE (RJ-45) Port: No
Certifications & Standards: Standard Safety: UL 60950-1, 2nd edition, CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition, CB to IEC 60950-1, 2nd edition with all group differences and national deviations, EMC Emissions: EN55022/CISPR22, CFR 47 Part 15, ICES003, VCCI-V-3, AS/NZS CISPR22, CNS13438, EN300-386, EN61000-3-2, EN61000-3-3, EN61000-6-1, EMC Immunity: EN55024/CISPR24, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11, EN300-386, Radio Immunity: EN301 489-1, EN 301 489-7, EN301 489-24, Cellular Radio: EN 301 908-1, EN 301 908-2, EN 301 511, 47 CFR Part 22, 47 CFR Part 24, EN 301 908-13
Features: Quality of Service (QoS)
Management: MIB, VLAN, SNMP v1,v2,v3, Telnet, Web-based Management, DHCP, Cisco IOS Embedded Event Manager, Cisco Security Manager, Cisco Configuration Professional, CiscoWorks
Network Technology: 10/100Base-TX, 10/100/1000Base-T
Security Features: L2TP, VPN, DES, 3DES, 128/192/256 bit AES, PKI, IPsec, NAT, SIP, Adaptive Control Technology, Firewall, Content Filtering, IPS, RADIUS, TACACS+
Power Source: AC Adapter
VPN Supported: Yes
Product Family: 800
